AIM
PRO FE

SRP* 5799 DKK

ArtNo. 140260

lizard´n´black

Comparison

ENJOY
THE RIDE

With the Aim FE we're redefining versatility. The included full-length mudguards, luggage carrier and lighting system mean it has everything you need right out of the box. There's a threaded bottom bracket and Internal Cable Routing, and the flat disc mount integrates seamlessly with the included kickstand. Carefully thought-out geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. Our Size Split system has an expanded range, too, so however tall you are there'll be an Aim FE that fits perfectly.

Frame Material

Aluminium Lite

Sizes

Size Split

Configuration

The Aim Pro FE is the boy scout of bicycles – prepared for anything. Fully equipped with mudguards, luggage carrier, lights and kickstand, it's perfectly suited to beating the traffic across town. And, come the weekend, the 100mm suspension fork and hydraulic disc brakes have adventure written all over them.

More Information

Bike category of use: 2

You can find more information about Bike Classification at the following link.

More Information

100
kg

Maximum rider weight

The rider weight refers to the weight of the rider including clothing and any equipment worn on the body.

Please see the table for information on the distribution of weight across the system in conjunction with compatible accessories (luggage carriers, bike trailers, etc.).

System weight table

Geometry

	XS	S	M	L	XL	XXL
Seat tube	340	370	420	470	515	560
Top Tube Horizontal	555	575	595	615	635	655
Seat angle	74°	73.5°	73.5°	73.5°	73.5°	73.5°
Head tube angle	68.5°	68.5°	68.5°	68.5°	68.5°	68.5°
Chainstays	427	427	450	450	450	450
Head tube	108	111	111	122	142	157
Wheelbase	1068	1082	1125	1146	1168	1190
BB-Height to Hub	52	52	65	65	65	65
Protrusion height - 80mm	707	720	759	792	824	858
Reach	384	398	409	426	441	457
Stack	595	598	627	637	656	670

Ergonomics

	XS	S	M	L	XL	XXL
Stem length	50	50	60	60	70	70
Angle stem	6°	6°	6°	6°	6°	6°
Handlebar width	680	680	680	680	680	680
Crank length	165	170	170	175	175	175
Length seat post	350	350	400	400	400	400
Diameter seatpost	27.2	27.2	27.2	27.2	27.2	27.2
Diameter tire maximum	708	708	747	747	747	747
Width tire maximum	60	60	60	60	60	60

All values are given in millimetres or degrees.

Mountain bikes remove barriers – and that's why we made the Aim Pro FE as adaptable as we possibly could. Fully kitted out with mudguards, a lighting system, luggage carrier and kickstand, it's ready to get you to work or haul your shopping across town. And, with its 100mm suspension fork, Shimano hydraulic disc brakes and 10-speed Shimano Cues gears, it's just as ready to take on weekend off-road adventures. Add grippy, comfortable 2.25in tyres and you're all set for pretty much anything.
